Interior

• Complete interior (over $100,000) was completed in 2012 by Karen Lynn.
• UPDATED in September 2017 by Patrick Knowles Designs.

Main Salon

• Entertainment center w/ 42" flat screen TV, Yamaha receiver and amplifier, Nuvo home video system, Indeka DVD receivers
• SMX A/C controls
• Custom upholstered leatherette sofa to starboard (8/11)
• Murray Brothers high gloss cocktail table
• Custom overhead soffit w/ lighting
• Custom geometric beige carpeting throughout (8/11)
• Upholstered lamberquins (8/11)
• (2) Oversized club upholstered chairs to port (8/11)
• Decorative marlin table lamp (8/11)
• Curved stairwell to skylounge
• Wood mini blinds throughout
• Wet bar w/ sink, Kitchen Aide icemaker, overhead glass and bottle storage

Day Head

Galley

Master Stateroom

VIP Stateroom

(2) Twin Guest Stateroom (Port & Stbd)

Lower Companionway

Skylounge & Helm Station

Electronics and Navigation Equipment

• Cameras -2012
• LCD Monitors in PH -2012
• Satellite TV System  - 2012
• (2) New ACR - RCL search lights -2012
• Replaced Trivoli lighting throughout vessel
• Replaced stbd Radar with Radar/Plotter: NavNet3D Black Box Multi Function Processor/ Chart Plotter includes US Charts
• Nauticomp 19" Titan Marine Monitor 100V AC 24VDC- for Radar
• Furano DRS12A 12Kw, 72 n.m. Digital Radar for the NanNet3D, less 4' or 6' Antenna
• Furano XN13A/6  6Ft Antenna Open Array
• GPS Furano GP330B GPS/WAAS Sensor - NMEA2000
• Furuno Nav Net Radar Plotter - 2012
• New Simrad Autopilot AP9 -2012
• Northstar 952X GPS
• Northstar 941X GPS
• (2) Furuno Anritsu 72-mile radars
• B&G water temp/distance log and depthfinder
• American bowthruster
• Standard hailer
• Naiad stabilizers
• Toshiba intercom
• Jog stick remote on helm chair

Flybridge & Upper Deck

• Aft of the skylounge thru double glass doors to the upper deck
• Aft control station
• (3) Grossfilex folding chairs
• Stainless steel ladder up to flybridge
• Control station on bridge w/ windscreen
• Additional seating
• Stainless steel rails and stantions
• Flybridge radar arch

Aft Deck

• U-Shaped bench seating
• (4) Gloster teak folding chairs
• Murray Brothers hi-gloss bow shaped teak table
• New none-skid decks (1/23)
• Fold-down ladder to bridge
• Wet bar w/ sink and storage to starboard
• U-Line refrigerator in cabinet to port (2017)
• CCTV security camera
• Overhead speakers
• Rocket launcher w/ (9) rod holders

Cockpit

Deck Equipment

• Marquipt 2500lb low profile davit
• (2) Freshwater washdown systems
• (2) Seawater washdown systems
• (3) Windshield washers and wipers
• (2) Anchors
• Maxwell 4500 windlass
• Anchor lines
• Retractable shore cords
• Switlik life raft (excluded from sale)
• Wet bar w/ icemaker & refrigerator
• Bottle and glass storage
• Cruisair chilled water A/C system
• Dual air horn
• Mounting chocks
• Phone/CATV inlets
• Omni DDS TV antenna
• ACR remote control searchlight
• Life jackets
• New 12 man Life Raft 2017

Electrical System

Recent Upgrades

September 2017

• Installed Furuno GP170 GPS NAVIGATOR W/O DGPS
• Shakespeare 390 SSB Antenna 23FT
• Shakespeare 5208 – R VHF Antenna 23FT
• New water maker membranes
• New water heater
• New fire extinguishers and engine room suppression system

October 2017

• Work done on air-conditioning system on board

November 2017

• Aft Deck ice maker
• Spray Rail repairs
• Rebuilt steps to the crew quarters

December 2017

• Hull Waved
• Bottom Painted
• Sanded and stained teak
• Some new interior in main salon
• Davit repairs/service
• New stabilizer seals
• New caulking around bridge windows
• New Hatches on bow
• New deck lighting, main deck and cockpit
• Engine room bilge tanks cleaned
• Replaced 4- 80 batteries on the port side.
• Port shore power converters unit was rebuilt.
• Replaced the ballast in the port inboard aft e/r fluorescent light.
• The engine room bilges were cleaned by MWM.
• The tender davit was rebuilt by Signature Marine.

January 2018

• Interior deep cleaning
• New interior wall panels
• Carpets professionally cleaned
• New chairs and pillows in salon
• Engine room cleaned and detailed
• New Davit motor
• New paint job on Davit
• New life raft
• Various new fresh and raw water pumps
• Compound and whole boat wax
• Cockpit bilge tanks cleaned
• Refinished teak decks
• Various paint touch ups
• Engine alignment
• Propellers removed, reinstalled, balanced
• Shafts pulled and Rebedded, new shaft seals
• The strut bolt was leaking and had to be replaced.
• All halogen lights in the cockpit step light were replaced with LED. The cockpit flood light was removed and repaired.
• Replaced light in the cockpit grill with 230 vac bulbs.
• BMC replaced some of the formic in the crew area.
• The shaft bearings were replaced.
• The rudder bearings were replaced.
• Bradford removed the bridge toilet for repair.
• The paddle wheel was replaced on the B&G speed log
• Replaced pressure switch on the port generator heat exchanger.
• Replaced fuel booster pump on the STB generator. Replaced the bilge pump in the crew cabin.
• Rebuilt the #1Racer filter in the transfer system
• Replaced all the DC halogen lights in the engine room with LED.

February 2018

• The wood base under the generator was replaced.
• Work done on exhaust system
• The hydraulic hoses for the stabilizers were replaced by Mendel Marine. Most of the hoses were replaced on the steering system by Mendel Marine.
• Both main engine fuel coolers were cleaned using Barnacle Buster.
• Port main engine crossover was removed by Metcalf Marine.

March 2018

• Repaired the port engine room exhaust fan.
• Rebuilt the port crew bilge control box.
• Replaced all the bolt and gasket on port gear box oil coolers.
• Replaced the control switch on the STB shore cord storage system controller. Replaced 3" check valve on the port main engine.
• Repair damaged wire on the front outboard port main engine. Replaced all the bolts and gasket on the STB gear box oil cooler.
• Replaced broken and damaged cushion clamps out board of the port gear box. Repaired damaged power cable to the STB guest toilet.
• Installed new flush timer on the STB guest toilet.

May 2018

• Repair made to VIP toilet discharge line.
• Reinstalled rope light outside port wheel house windows.
• Metcalf removed STB crossover pipe and mixer. Turbo rings removed so they could be refurbished.
• STB exhaust fan removed so that the air plenum could be repaired.
• New thermostat in crew area.

June 2018

• Both generator heat exchangers cleaned using Barnacle Buster.
• Plug replaced on port aux gear control. Tess Marine electric.
• Replaced crew toilet water solenoid valve.
• Replaced relay on crew toilet macerator pump.
• Rebuilt crew macerator pump.

July 2018

• Install new compensator on STB exhaust in crew area.
• Install new temperature switches in the fiber glass exhaust pipes in crew area.
• Metcalf installs STB crossover pipe and stainless-steel crush ring.

August 2018

• Replaced the air conditioning compressor for the lower staterooms
• STB battery charger replaced by Tess Electric.
• Replaced the stainless steel braided hose to the mixer gauges.
• Metcalf Maine installed new turbo ring to STB main engine

September 2018

• Cleaned Port main engine plates plate cooler.
• Port stabilizer potentiometer was replaced . STB one was tested and found to be OK.
• New Batteries installed on the STB side.

October 2018

• New electric fuel pump on the main generator.
• Installed new heat exchanger on the port generator.
• New pump and motor replaced on the #1 air conditioning raw water pump.
• New tachometer installed on the STB main engine.

January 2019

• Added AIS System Furuno F170

February 2019

• Cleaned and Serviced Port Engine Injectors
• New Sea Power Converter

September 2019

• Port side Delta T fan replaced

August 2020

• New bottom paint
• All new thru-hull sea valves
• Stabilizers serviced

January 2021

• New and rebuilt engine monitors and shutdown
• Removal of cockpit and swim platform teak decks - replaced with non-skid decks

November 2022

• Entire new main engine exhaust by Design Engineered Solutions (D.E.S)
• New exhaust spray rings by D' Angelo Exhaust
• Upgraded and renewed aft deck teak
• Fire equipment updated by Fireline
• Steering lines - New 10/22
• New handlers and compressors for VIP, stbd, twin, galley and port twin

January 2023

• New non-skid on aft deck

Engine / Mechanical Equipment

• Twin Deutz TBD620 V-16 Main Engines 3100HP (Stbd engine rebuilt at 3860 hrs / Port engine rebuilt at 3810 hrs. Sbd engine now at 4147 = 282 hrs after rebuild Port engine now at 4095 = 285 hrs after rebuild.
• Complete Cylinder Liners, Pistons and Bearing rebuild by Marine Diesel Service 285 Hrs ago. At a cost of $450,000 (2011)
• Range - 1000 Miles at 10 Knots - 582 Miles at 25 Knots
• Northern Light 38Kw Generators (2012) (Port hrs 1472 - Stbd. hrs 849)
• Entire new main engine exhaust - (11/22)
• Power Take- Off for Bow Thruster (2012)
• Water Marker membranes (10Hrs ago) (2017)
• Replaced "ALL" Hydraulic hoses throughout boat (2012)
• Replaced Icemakers (2012)
• Exhausts rebuilt in 8/2018 by Metcalf Marine Exhaust for $100,000
• New Cruisaire A/C system (2012)
• All air handlers throughout (8/11)
• Naiad stabilizers
• American bowthruster
• New ships monitor system w/ new display screen
• Sturdy engine synchronizers
• Fuel prime system
• Oil change system
• ZF Transmissions 3.2.1 reduction
• Racor fuel filters
• Hydraulic power steering
• Delta-T engine room ventilator
• Watermakers 1500 GPD watermaker
• Vulkan coupling (8/11)
• Exhaust stainless steel covers (8/11)
• Fire extinguishers (8/17)
• Fire extinguishers re-certified (8/18)
• RPM speed 860 29 KNTS
