Cockpit/Lazarette/Swim Platform and Aft Deck

All the way aft is a small cockpit with a sink and fish cleaning station on the port side (drain added during 2015 refit) with drawers for tackle underneath. On the starboard side of the cockpit there are (2) 100-amp, 3-phase electrical inlets. On top of and at the center of the after bulkhead there is a SS mounting pin for the manual passeralle. To starboard is a transom door which leads from the cockpit down to the integral swim platform. The swim platform has (2) SS bollards and (2) Maxwell stern warping winches outboard to port and starboard, a folding SS swim ladder and a freshwater handheld shower. Both the swim platform and cockpit have teak decking. In the lazarette under the cockpit there is a backup hydraulic pump for the steering system, new Side Power stern thruster, spare 250lb. Kedge anchor with about 50' chain, and miscellaneous spare parts.

A ladder leads from midships of the aft bulkhead of the cockpit to the aft deck above. The aft deck has a removable isinglass curtains, teak decking, and a stairway with teak steps to the boat deck above. On the port side of the aft deck are a built-in, L-shaped settee and small coffee table. To starboard is a varnished round dining table with matching chairs/seating for up to six.

Main Salon

Sliding glass doors lead from the aft deck to the Main Salon. (Doors can be made Opaque electronically if one wants privacy when docked "stern to). Paneling in the salon and throughout the yacht is Cherry. The carpeting here is new beige and white flecked. Outboard on both sides of the sale are three large thermal pane windows which give this area a very open feel and provides people sitting or standing the ability to enjoy panoramic views. (Hunter Douglas "Duette" blinds for the windows here as well as for the other windows and ports throughout the boat). At the port end of the salon, just forward of doorway from the aft deck is a cherry wood bar with blue/grey granite bar top.

Amenities of the bar are:

Three Stidd type bar stools, leather upholstered seat and back cushions

Frigidaire icemaker

Under counter refrigerator

Small sink

Storage cabinet for glasses and liquor

Additional cupboards and bookcase behind bar in the after bulkhead.

Forward of the bar on the port side of the salon are a beautiful blue grey leather semicircular settee and a large coffee table with storage underneath. On both sides of the salon are built in cherry cabinets. Opposite the settee, starboard side, is a retractable 54" flat screen TV with storage cabinets underneath. Forward of this, at the starboard end of the salon, is a built-in desk/computer station with a chair. Lighting in the salon consistsof:

3 Brass wall sconces

25 small halogen, overhead, recessed lights

5 110V AC/24V DC large round brass overhead lights

All accent (rope) lighting

Other features:

(1) Set of AC digital controls for (2) new air handlers

(2) New AV speakers

Master Stateroom

Varnished teak with nonskid steps lead down from the starboard aft corner of the salon to the private, full beam master stateroom below. (Steps here, as well as from the salon to the galley and from the pilothouse to below and forward, were custom built at Front Street Shipyard). At the bottom of the steps there is a secondary entryway to the engine room. A teak and holly companionway leads from here to the master. Farther along the companionway on the port side is utility room with a linen locker, Dometic Combo Washer/Dryer and two access hatches for the after-fuel tank and gray water tank. On the starboard side the companionway is a small storage room which has a fold down desk and seat, a safe, storage for storm ports, a fire extinguisher and fire hose. (Room was used by the present owner as a Ham Radio Room and is wired accordingly). Two port lights bring added light to this area.

The master stateroom has (6) opening port lights (two to port, two to starboard and two larger ports in the after bulkhead which open up to the cockpit. There are screens and deadlights for all of these port lights as well as for the port lights throughout the rest of the boat). There is a king size berth mounted fore and aft on the centerline of the stateroom. On either side of the berth are built in bureaus, cubbies and bookshelves. Outboard on the starboard side of the room is a newly recovered settee. Above and behind the settee are additional cubbies and cabinets for storage. Mounted into one of the cabinets is a new Garmin GPS 6212. Farther forward is a double door hanging locker. On the port outboard side of the room there are additional cabinets and a built-in vanity with mirror and stool. Mounted on the forward bulkhead opposite the foot of the berth is a 54" Samsung TV. Below are additional cabinets for storage.

Lighting in the master consists of:

(2) traditional 110v classic steamer lights over berth

(4) large, round, brass 110v/24v lights overhead

(11) flush mounted Halogen lights overhead

At the port forward end of the master is the ensuite bath.

Double sink in vanity

Gold-plated fixtures (sinks and shower)

Granite countertop

Tile flooring (heated) and tile in shower

Dometic VacuFlush head

Mirrored cabinets over sinks for toiletries and medicine

Storage cupboards under sinks, as well as deep, custom built cubbies behind toilet and a stand alone varnished box for paper goods.

Lighting consists of

(5) Halogen overhead lights

(1) large, brass round 110v/24v light

(1) Halogen light in shower

(1) small, brass, round 110v/24v light in shower

Extractor fan

Galley/Dinette

Teak steps lead from the foward end of the main salon up to the galley and dinette. There is beautiful teak and holly sole. The spacious galley is to port and has an abundance of natural light from two large windows.

Other features and equipment include:

Black and white granite counter tops

Deep, SS sink

Air Handler

Miele 5-burner glass cooktop with warming zone

Miele under counter oven

GE Profile Convection/Microwave oven

KitchenAid under counter dishwasher

Sub-Zero full size refrigerator

Lighting consists of:

(10) Halogen recessed overhead lights

(4)round, brass 110v/24v lights

Smoke Alarm

(2) AV speakers

The dinette is starboard and has an upholstered blue leather, semicircular sette with large rectangular granite top table. In addition, there are two stools in board tha swivel so that they can be stowed under the table when not in use.

Pilothouse

Just beyond the galley/dinette area is the Pilothouse. The Pilothouse can also be shut off from the galley by means of a pocket door. To starboard, aft, is an on-deck head. Adjacent and outboard of the head are steps which lead to the flybridge above. A the helm is a spoked destroyer type wheel with a varnished wood rim. On the port and starboard sides of the pilothouse are varnished dogged and gasketed wing doors.

On the port aft side of the pilothouse is a leather bench seat with (4) small drawers and a long chart drawer under it. Above and inboard of the bench seat are bookshelves where the yacht's drawings and equipment manuals are stored. Below these, in a cabinet are the "brains" for the VSAT and Iridium communication systems (run through Panasonic PBX), an HP Laser Printer and box for KVH TV. Under this cabinet are the A.C. and D.C. panel for the bridge electronics and the Naiad controller for the stabilizers.

At the port side of the pilothouse console is a chart desk/nav station which pulls out and away from the console for ease of studying and making notations. On the console are (2) Nauticomp Display screens for Nobeltec, Radar, NAVNET and surveillance cameras (2 in engine room, one aft, and one on flybridge). In addition, there is a Garmin GPS-Map 7215 with Radar, Chart Plotter and the yacht's Maritron Monitoring System. Mounted above the console are gauges for main engines, alarms, tachometers, etc.

Guest and Crews Quarters

Teak steps lead from the starboard forward side of the pilothouse to the guest and crews' quarters below. At the fooot of the stairway which leads to two identical twin berth guest staterooms. At the beginning of this companionway is an access hatch for the inspection plate for the grey water tank. Further along to starboard is a full length closet for linens, bathroom supplies, and small bag storage. Aft to port are the staterooms. Both staterooms are paneld in cherry and have full twin sized berths with two deep drawers under each.

In addition, both staterooms have:

Built in night table with two drawers between berths

Full length half locker with shelves for pillows, blankets, etc.

Full length, double door hanging locker with AC digital controls inside.

22" TV mounted on the forward bulkhead

Storage cubbies above outboard berth

Sony Am/Fm Radio and Amplifier

Sony 10 Disc Automatic Changer

Panasonice phone and Intercom

Mutiplug strip

(2) Opening portlights and Hunter Douglas shades

(8) Halogen flush mounted overhead lights

(1) Large, round brass 110v/24v light

(1) Smoke detector

(2) Overhead flush mounted audio speakers

Accent lighting

Ensuite head

Head:

Tile floor in head and shower

Single sink with Corian countertop in cherry vanity

Gold plated faucets and shower head

Mirror faced medicine cabinet over vanity

Built in waste bin in vanity

(1) Opening portlight with Hunter Douglas blind

(1) large round brass 110v/24v light

(1) small, round brass 110v/24v light (in shower)

(1) extractor fan

Towel racks

VacuFlush head

Crews Quarters

Directly ahead of the bottom of the stairway from the pilothouse is a doorway which leads into the crew's mess and crews' accommodations. Flooring here and throughout the crew's quarters is goam backed linoleum (simulated oak). Paneling in this area is light wood.

The crew mess has:

Upholstered L-shaped settee with a hi-lo table and small galley.

Thermador 2 burner glass cooktop

Amana Microwave

Magic Chef refrigerator (small)

22" TV

Bookshelves

Round SS opening port light in the hull side

Laundry

Opposite the crew mess is the yacht's Laundry room which has:

Full size Miele Washer and Dryer

Large SS laundry sink and faucet

Storage Pantry

Laundry detergent and cleaning supply cabinet

Perlick Freezer

Bilge Storage, Bow thruster compartment

In the crew quarter's companionway, there is a hinged hatch with a pneumatic ram assist that provides access to a large storage area below. This area is well lit with two large AC fluorescent light fixtures. It is an ideal location for storing extra cases of water, soft drinks, etc. On the port and starboard sides of this compartment are racks for bins where spare parts are stored. All the way forward is the tunnel for the bow thruster. Just aft of this is a large household type chest freezer. At the after end of this area are the black water tank and grey water tank. Some of the other gear and equipment housed here are:

NuTone central Vacuum system

30-gallon ship's compressed air reservoir

Personal Safe

(4) Sealand toilet vacuum accumulators

Captain's Cabin and Crew Cabin

At the forward end of the crew's quarters there is a captain's double berth cabin to starboard and an upper/lower berth crew cabin to port. Both cabins have an ensuite head with toilet and access to a shared shower.

The captain's cabin has:

Double berth with four drawer's underneath

Nightstand with two drawers inboard built in next to the berth

(4) cuddy lockers above and outboard of berth

Full length, double door hanging locker

(2) round dogged and gasketed port lights

Overhead opening hatch

Garmin GPS-Map 6212 flush mounted on inboard bulkhead

(2) Audio speakers

Ensuite head with tile flooring, sink in vanity with Corian countertop, large mirrors on both sides of this area, round opening port light, VacuFlush toilet and curved door to shared shower.

Flybridge and Boat Deck

Steps lead from the starboard side of the pilothouse up to the flybridge. The flybridge has a fixed, anodezed aluminum hardtop with canvas cover, removable Isinglass curtains with U zip windos, painted nonskid decking, and a helm station with full controls and electronics. At the helm are three helm and companion chairs on pedestals. Under the helm is space for storage and a radio battery bank consisting of (2) 12 volt DC sealed batteries and a ProSport 20 amp charger. On the port side of the bridge is a wet bar with polished stone top and SS sink. Below are a Vitrifrigo beverage refrigerator and a U-Line icemaker. There are dogged hatches under the helm and wet bar for access to these storage spaces as well as hook ups for compressed air and fresh water. Overhead on the bridge are two audio speakers.

Aft to port are built in bench seats with storage underneath. In front of the bench seats are a small varnished teak cocktail table and two varnished teak folding chairs.

Lighting on the bridge consists of:

(6) overhead LED lights

(2) flush mounted deck level lights

At the starboard aft end of the flybridge is a curved companionway which leads to the boat deck/sun deck a few steps below. Here and contiguous with the hardtop there is an integrated radar arch and mast. On the back of the arch, port and starboard, are louvered air intake and extractor vents for the engine room with a manually operated dampener lever below each. On the port side is an aluminum ladder for access to the top of the arch and folding mast. Mounted on the back of the arch are two horseshoe type lifesaving rings. Outboard to port on the sun deck is a portable Steele Propane Barbecue Grill.

The sun deck has spacious, painted nonskid area for dining or sunbathing. There is a varnished teak dining table and eight varnished folding chairs here, as well as two varnished steamer type chairs (matching cushions for all of the chairs). To port and starboard are raised ventilated dunnage boxes that also have seat and back cushions. On the front of each box is a built-in marinized stereo speaker.

Farther aft and mounted on the centerline is a Nautical Structures davit (2,500 lb. capacity) with an extension boom. Stowed to starboard is a 2010 15' Novurania RIB with a 90hp Yamaha. A manual aluminum and teak passerelle is stowed under the tender. All the way aft on the centerline at the stern are a flagstaff and stern light. To port, at the aft end of the sun deck, is a curved stairway with varnished teak handrail which leads below to the aft deck.

Side decks, Weatherbreak, and Foredeck

Port and Starboard:

Wing doors from aft deck

Engine room access from fiddley on the starboard side deck

Waist high bulwarks with varnished teak handrails on SS stanchions

Teak deck

SS inboard grab rail

(2) round 110v/24v overhead lights

(2) SS cleats and fairleads

(3) freeing ports

(3) scuppers

Side Bulwark doors with hardware for tide ride boarding ladder

Tide Ride boarding ladder stowed inboard on starboard side deck

Fuel and freshwater fills under steps from side decks to weather deck. Single point fueling with CamLock

Weatherbreak:

Built in seating in front of house with storage underneath and waste pump out fitting

Fresh water hookup starboard side

(2) Hubble 110amp shore power Inlets, GFCI 110 volt AC outlet, dockside phone and cable television jack connection, plug for boarding bell in small locker port side

Foredeck:

Painted nonskid

(2) Large Opening hatches in front of weatherbreak over crew quarters

(2) Large, ventilated dunnage boxes - one port and one starboard with deck level lights

SS bollard and fairlead - one each side

SS cleat and chock - one each side

Freeman hatch for chain locker and forepeak - forward centerline foredeck

Maxwell 5000 anchor windlass with two horizontal gypsies and one vertical warping capstan

Fire main and fresh water washdown bib to port of windlass

(2) Pool-N 200lb. galvanized steel Navy stockless anchors in steel lined anchor pockets port and starboard in the bow

Anchor chain: Starboard 300'/Port 500'

Open fairlead with nylon roller on stem

SS Hoop style bell stand with 10" ship's bell-aft of windlass

Construction and Paint

Electric welded Marine grade aluminum done to high standards.

Aristo Awlgrip hull. Matterhorn White Awlgrip superstructure.

Bulwarks painted from rubrail to caprail.

Engine and Mechanical Equipment

(2) Caterpillard D34068 engines

Horsepower: 380hp @ 1800 RPM each

Speed and Consumption: 9.5kts @ 1350 rpm with one generator = about 18gph. 8.5 kts @ 1200 rpm with one generator = about 13 gph.

The midships engine room with full headroom is accessed from a watertight door and fiddley on the starboard side deck of the yacht. Twin engines and three generators are all located here.

Main engine and generator fuel transfer and fill manifold w/Racor #1000 fuel water separator

Electric fuel transfer pump

Nelson Fuel water separating system

Original Wagner Steering System with upgrades/redundancy. Runs off PTO's on mains or on a 7 1/2 hp electric hydraulic pump in engine room or on a backup electric hydraulic pump in the lazarette

Gearboxes: Twin Disc model MG516, 2.06 to 1 ration

LoRez type shaft couplings

Tides Dripless shaft seals

(2) Nibral 4 bladed props (1) spare set stored on shore

Shaft: 3", 2-piece SS (1) spare stub shaft on board

Spur Cutters

Marine Air Dometic chilled water Ac system. 108,000 BTU's with reverse cycle heating. (3) compressors

Naiad Stabilizers, shafts, seals, beaings

KoopNautic 60hp Bow Thruster

SidePower 20hp Stern Thruster

Air Compressor

(2) SS hot water heaters, dual element

Watermakers, Inc. 2,500 gpd watermaker

DeAngelo Main Exhaust System

Burkes AC Electric main fire and bilge pump

Snap-On toolbox

(2) Sliding worktops on top o main engine railings

SS sink with faucet

Storage drawers

Vise

Tanks

Fuel: 5,800 gallons in (6) welded aluminum tanks

Port and Starboard forward 1,520 gallons

Engine room forward bulkhead mounted day tank 200 gallons

Port and Starboard engine room fuel tanks 777 gallons each

Aft fuel tank 986 gallons

Potable Water: (2) welded aluminum integral tanks 925 gallons located in guest stateroom bilge port and starboard separated by a centerline bilge.

Black Water: 860 gallons in one welded aluminum integral tank in bow thurster compartment

Gray Water: (2) welded aluminum tanks, 460 in bow thruster compartment and 40 gallons in aft engine room centerline bilge

New oil: 100 gallons

Used oil: 120 gallons

Deck Equipment

(1) 2010, 15' Nautica RIB w/ 90 hp Yamaha outboard

Triple Kahlenberg horns

Loudhailer

Nautical Structures EZ2500ex

Boat crane

Passerelle: Fixed davit system

MarQuipt boarding steps

Integral swim platform with underwater lights and SS folding ladder

Outdoor shower (at swim platform)

BBQ grill" Steele stainless, propane

Cockpit fish cleaning station

Portable rod holders

(9) fenders

Numerous dock lines

Audio/Visual

55" Samsung LCD TV - Salon

55" Samsung LCD TV - Master

(3) 22" TV's - guest staterooms, crew mess

Panasonic Stereo/CD changer in guest staterooms

Stereo Surround Sound System

(7) Niles area Entertainment Music System Control Panels

Safety and Fire Protection

Security: CCTV systems with (1) aft deck, (2) engine room, and (1) FLIR cameras

Firefighting:

Automatic/Manual Halon 1301 with automatic shutoffs for engine room blowers and manual shutoffs for intake and discharge ventilation dampeners. Suppresion system with automatic shut downs on mains, generators, and fans.

Smoke detectors throughout

Fire/emergency bilge manifold

(2) Fire mains (one in lazarette; one on foredeck)

(2) Freshwater fire mains (one in master stateroom; one in laundry)

(2) Electric and hydraulic pumps (fire and bilge)

16 Handheld fire extinguishers

Safety Equipment:

(2) Revere 6-person Elite life rafts in canisters with hydrostatic releases

(4) Horseshoe life rings

Flare kit

50 Offshore Elite life jackets

(2) ACR Searchlights

(2) First Aid Medical kits

(2) Small Oxygen tanks

(8) Immersion Suits

(5) Watertight bulkheads

Full set of porthole covers

(3) EPIRB's

(1) Fully equipped Ditch bag

Electrical System and Equipment

110V/240V AC, 24V DC

Electrical outlets: (2) Hubble 100amp three phase shore power inlets in the forward weatherbreak and (2) aft on the starboard side of the cockpit. Yacht can be fun off:

(1) 100 amp three phase power cord from bow or stern

(2) 100 amp single phase power cords from or stern

(1) 100 amp single phase cord with power management

Shore cords: (2) 100 amp, 3 phase 50' cords with Hubble plugs

Adaptors for 100 amp three phase to single phase

(2) Smart boxes for 50 amp plugs

Electrical Panels:

Main electrical switchboard panel in engine room

Sub panel in pilothouse

Atlas Energy Systems, Inc. single phase 120/240 volt, 60 cycle shore power converter

Atlas Energy Systems, Inc. Shore power SmartBox

Generators

(2) 40 KW Northern Lights generators

Port 40KW=20,379 Total. Rebuilt at 12,400 hrs.

Port 40 KW = 20,433. Rebuilt at 13,800. 6,333 since rebuild.

Center 22KW = 12,544

Batteries

(8) 8D house

(2) 8D engine starting

(4) 8D for stern thruster

(2) 12v for radios flybridge

Victron 24v, 5000 watt/120 amp battery charger/Inverter

ProSport 20 amp/24v charger Flybridge

Victron 24v/50 amp charger lazarette

Victron 24v/50 amp charge engine room

Battery Room:

Located under guest staterooms and accessed through a hatch below p and s inboard berths.

24v DC house battery bank in acid proof ventilated boxes

Rule 3,500 gallon per hour submersible automatic/manuel bilge pump

Sperry gyrocompass

Simrad RC35 fluxgate heading sensor

Fluorescent light

Electronics and Navigational Equipment

Pilothouse:

ZF Electronic Main Enge controls

SEA 330 HF/SSB radio telephone

Icom #ICOM602

DSC VHF

Garmin GPS Map 7215 w.radar, Mareton Monitoring System, GPS, chart plotter.

(2) Garmin Map6212 - master stateroom & Captain's cabin.

(2) Nauticomp 19" Monitors w. Nobeltec, CCTV, FLIR, NAVNET and Radar.

Electronic maps for Bahamas, Caribbean, and West Coast from Canal to Alaska

Cruising Guides and Paper Charts for trip from Caribbean to Alaska

VSAT (satellite phone, internet and data)

Iridium Satellite phone

Telephone system: Panasonic D1232 hybrid

SidePower stern and boat thruster jog controls

Simrad AP 50 with updated software

Simrad jog lever steering control

Simrad AIS Transponder

Naiad Stabilizer controls

Sperry Gyro Compass

(2) Niles Entertainment System Control Panels

Capac model #50030 hull potential meter

(2) B & G Hydra 2000 LCD navigation displays

(2) ACR Remote Searchlight controls

(3) Northern Lights remote start/stop and preheat generator panels with analog gauges

GEMS tank sender gauge w/selector for (6) fuel tanks & p. & s. water tanks

Annunciator Alarm System for bilge, fire running lights, day tank, sump tank

On/Off switches for Bilge pumps, deck lights, passage light night lights, helm light

Emergency stop controls

Gauges for main engines & gearbox

On/Off for Wiper/Clear View, washer/heater functions for Clear View

On/Off switches for Mast head light, running lights, horn, anchor light

Flybridge:

ZF Main Engine Controls

Garmin Map 7215

(1) Nauticomp 19" Monitor

Simrad AP50 remote

Simrad Jog Lever Steering

Naiad Stabilizer Controls

SidePower Stern & Bow thruster toggle controls

Icom #ICM602

DSC VHF

(2) Niles Entertainment Systems Control panels
